Features:
- Unique design to suit various materials like HM, HDPE, LDPE, LLDPE & Biodegradable Polymers
- Output range starting from 25 Kgs/Hr to upto 500 Kgs/hr
- Grooved Feed type Nitrided Barrels
- Nitrided Screw-Barrel made of special alloy steel for longer life
- Helical gear box with inbuilt thrust bearing
- Single station / two station type surface rewinder
- Uniquely designed spiral type of die suitable for HM-HDPE materials & LDPE-LLDPE materials
- Bubble Calibrating Basket / Iris ring
- Universal gusseting arrangement
- Embossing roller attachment
- Centre & Side Slitting arrangement
- High density ceramic type band heaters
- SSR based all heating zones
- Single point synchronization of whole line with AC motors and AC invertor drives.
Applications:
- Film For Carry Bag, Shopping Bag, D Cut Bag Etc.
- Film For Groceries Bag, Trash Bag Etc.
- Film For Liners
- Stretch Film
- Shrink Film
- Lamination Film
- Mulch Film
Technical Specifications:
| Model | KBFH/35-G | KBFH/40-G | KBFH/47-G | KBFL/51-G | KBFL/55-G | KBFL/65-G |
| Material To Be Processed | HM, HDPE | HM, HDPE | HM, HDPE | LDPE, LLDPE | LDPE, LLDPE | LDPE, LLDPE |
| Screw Dia | 35 mm | 40 mm | 47 mm | 51 mm | 55 mm | 65 mm |
| Barrel Feed Type | Groove Feed | Groove Feed | Groove Feed | Groove Feed | Groove Feed | Groove Feed |
| Layflat Film Width Range | 100 to 450 mm | 150 to 600 mm | 200 to 800 mm | 600 to 1000 mm | 800 to 1300 mm | 1000 to 1500 mm |
| Film Thickness Range | 20 to 100 micron | 20 to 100 micron | 20 to 100 micron | 20 to 100 micron | 20 to 100 micron | 20 to 100 micron |
| Maximum Output | 25 Kg/Hr | 40 Kg/Hr | 60 Kg/Hr | 75 Kg/Hr | 100 Kg/Hr | 130 Kg/Hr |
| Die | Stationary Die | Stationary Die | Stationary Die | Stationary Die | Stationary Die | Stationary Die |
| Winder | Single Station Surface Wnder | Single Station Surface Winder | Single Station Surface Winder | Double Station Surface Winder | Double Station Surface Winder | Double Station Surface Winder |
| Machine Connected Load | 20 KW (27 HP) | 29 KW (39 HP) | 38 KW (51 HP) | 47 KW (63 HP) | 59 KW (79 HP) | 77 KW (103 HP) |
| Dimensions ( L x W x H ) Apprx |
7 x 7 x 10.5 Feet |
8 x 8 x 12.5 Feet |
10 x 10 x 15 Feet |
25 x 10 x 16.5 Feet |
25 x 10 x 18 Feet |
30 x 12 x 20 Feet |
| Optional Attachment | Rotating Die | Rotating Die | Rotating Die | Rotating Die | Rotating Die | Rotating Die |
| LDPE, LLDPE Attachment | LDPE, LLDPE Attachment | LDPE, LLDPE Attachment | HM, HDPE Attachment | |||
| Double Station Winder | Double Station Winder |
